T83 passive Hi Z and Low Z linear source column speaker is built with 8 pcs 3’’ neodymium drivers. The drivers are arranged by elaborate calculation and PhycalTM physical calibration technology, which makes T83 with wider near-field horizontal and vertical coverage than the normal column speaker, to meet various demands.
T83 is equipped with wall mount brackets to adjust the angle horizontally and vertically. T83 is inbuilt with voltage and impedance output switch tap, which makes T83 with more applications.
Features
- Waterproof Rating IP54
- Customized ProDriver
- Unique Driver Protection Circuit
- Durable Polyurea Coating
Specifications
Type | Hi Z and Low Z Linear Source Column Speaker |
Driver | Full frequency 8×3” |
Frequency Response(-10dB) | 110Hz-20kHz |
Horizontal Coverage | 120° |
Vertical Coverage | 40° |
Impedance Power | 240W |
70V Power | 120W/60W/30W/15W |
100V Power | 120W/60W/30W |
Maximum Calculated SPL/1M (Continuous/Peak) | 124dB/130dB |
Rated Impedance | 4Ω |
Crossover Mode | / |
Input Connectors | Euroblock |
Cabinet Material | Wood+Plastic |
Coating | Durable Polyurea Coating |
Cabinet Color | Black is the default color. Contact Audiocenter for customization |
Grille | Iron mesh |
Included Accessories | Wall-mount Bracket |
Optional Accessories | / |
Speaker Dimension(W×H×D) | 121x918x191mm |
Carton Dimension(W×H×D) | 1069x185x445mm |
Net Weight | 7.0kg |
Shipping Weight | 17.0kg(2pcs) |
Drawing
T83
Hi Z and Low Z Linear Source Column Speaker
T83 passive Hi Z and Low Z linear source column speaker is built with 8 pcs 3’’ neodymium drivers.
