Overview
The T43+ linear source column speaker has been comprehensively upgraded, with refined acoustic tuning, a fully re-engineered structure, and IP56-rated protection. Ready for indoor and outdoor sound reinforcement. Next-level performance, in every way.
T43+ passive Hi Z and Low Z linear source column speaker is built with 4 pcs 3’’ neodymium drivers. The drivers are arranged by elaborate calculation and PhycalTM physical calibration technology, which makes T43+ with wider near-field horizontal and vertical coverage than the normal column speaker, to meet various demands.
T43+ is equipped with wall mount brackets to adjust the angle horizontally and vertically. T43+ is built-in with voltage and impedance output switch tap, which makes T43+ with more applications.
Features
- IP56-rated protection
- Customized ProDriver
- Unique Driver Protection Circuit
- Durable Polyurea Coating
Specifications
Type | Hi Z and Low Z Linear Source Column Speaker |
Driver | 4×3” Full frequency |
Frequency Response(-10dB) | 110Hz-20kHz |
Horizontal Coverage | 120° |
Vertical Coverage | 40° |
Impedance Power | 120W |
70V Power | 60W/30W/15W/7.5W |
100V Power | 60W/30W/15W |
Maximum Calculated SPL/1M (Continuous/Peak) | 121dB/127dB |
Rated Impedance | 8Ω(+1,-1) |
Crossover Mode | / |
Input Connectors | Euroblock |
Cabinet Material | Wood |
Coating | Durable Polyurea Coating |
Temperature range | -20℃~+50℃ |
Cabinet Color | Black is the default color |
Grille | Aluminum mesh |
Included Accessories | WM05-BL/WM05-W |
Optional Accessories | WM07-BL/WM07-W |
Speaker Dimension(W×H×D) | 121x515x157mm |
Carton Dimension(W×H×D) | 697x186x232mm |
Net Weight | 4.0 kg |
Shipping Weight | 5.5 kg |
T43+
Hi Z and Low Z Linear Source Column Speaker
The T43+ linear source column speaker has been comprehensively upgraded, with refined acoustic tuning, a fully re-engineered structure, and IP56-rated protection.
